0.6 Inch Monochrome Green Micro OLED Display 800x600 SVGA HDMI Kit for Night Vision
0.6 inch SVGA Monochrome Green Micro OLED 800x600 with HDMI Board for Head-Up Displays (HUD)
This 0.6-inch Micro OLED Mono Green microdisplay delivers an 800×600 (SVGA) resolution on a silicon-based AMOLED backplane. With an ultra-high contrast ratio of 100,000:1 and compact 12.06×9.06mm; this micro oled display module comes equipped with a compact HDMI controller board. Designed for high brightness, extreme contrast, and rapid response times, it serves as a perfect commercial alternative or drop-in replacement for OLightek and eMagin microdisplays;
Potential applications： Night Vision Goggles (NVG) & Helmet Mounted Displays,Thermal Imaging Scopes & Infrared Aiming Sights,Defense, Military, and Law Enforcement Targeting Systems,Medical Diagnostic Displays & Portable Medical Imaging
Specifications
| Specification | Value |
|---|---|
| Model No | HG060SVGA |
| Display Size | 0.6 inches |
| Resolution | 800 × 600 (RGB vertical stripe) |
| Active Pixels | 800 × 604 |
| Luminance | 200cd/m² (Color), 500cd/m² (Mono White), 10000cd/m² (Mono Green) |
| Pixel Size | 15µm × 15µm |
| Pixel Array | RGB Vertical Stripe |
| Active Area | 12.06 mm × 9.06 mm (Diagonal: 0.60") |
| Gray Level | 256 |
| Interface | MIPI (1 lane) + I²C |
| Contrast Ratio | >10,000:1 |
| Life (T90) | 500 hours @ 3000 cd/㎡; 600H@ 6000 cd/㎡; 600H@ 10000 cd/㎡ |
| Operating Temperature | -40℃ to +65℃ |
| Storage Temperature | -55℃ to +90℃ |
| Operating Humidity | ≤85% RH (without condensation) |
| Lifetime | 20,000 hours at specified luminance |
| Net Weight | 1.7 g |
Key Features
High SVGA Resolution Microdisplay
800x600 Active Pixels: Packed into a compact 0.6" form factor, delivering crisp text and tactical graphics for near-eye optical systems.
15µm Pixel Pitch: Ensures exceptional pixel density and clear image details, eliminating the "screen door effect" in professional viewfinders.
Vibrant Monochrome Green & Ultra-High Contrast
10,000 cd/m² High Luminance: Outstanding green monochrome brightness, offering crystal-clear visibility for advanced night vision goggles (NVG) and thermal scopes.
10,000:1 Contrast Ratio: Delivers deep blacks and perfect grayscale rendering, which is essential for rapid target identification in professional environments.
Low Power Consumption for Wearable Devices
Silicon-Based AMOLED Backplane: Engineered for maximum energy efficiency, significantly extending the battery life of portable thermal imagers and smart helmets.
Wide Operating Temperature: Built to withstand harsh environments from -40°C to +65°C, ensuring industrial-grade reliability.
Drawing& Pindefinition
